Nome do produto : HC-HE / HC-HEI

Auto / Manual Photo Electric Edge Guide Contriller

Features

  • Can detect without being affected by outside lights.
  • Can detect without being affected by dust and wadding.
  • Can sense and detect any color.
  • Low trouble, easy to maintain, long life.

Driving

  • Motor : 1/2HP, 4P 220/380/440 3 phase 50/6oHZ
  • Pump capacity: 3L/min
  • Oil tank : 15L
  • Hydraulic pressure : 15kg/cm2
  • Oil : CPC RL68 / SHF 32
  • Temperature : -10°C~+60°C
  • Oil cylinder: Φ40, 300 mm (option)

Inquérito
Introdução de produto

Sensor

  • Optical : HE1
  • Controller voltage : AC220V
  • Small : material max thickness : 15mm (standard)
  • Large : material thickness : 16-30mm (option)

Function

  • Cylinder press : 180kg (Φ40 cylinder)
  • Operating speed : 30 mm/sec (Unload)
  • Accuracy : 0.1mm
  • Sensitivity: 0.2sec

Other

  • Weight : 40kg
  • Installation : horizontal


The model HC-HEI is avaiable. HE-HEI os same as HC-HE biut without manual control.
